ZTON 1505 - Truck Crane

Truck cranes are a type of heavy equipment that is widely used in the construction industry to lift and move heavy loads. This tool consists of a crane mounted on a truck, allowing high mobility and flexibility in lifting work in various locations. The crane can be adjusted to the required height and reach by adjusting the height of the arm (boom). The crane is used to hang and lift loads according to the load characteristics. will be appointed.



DESCRIPTIONUNITZTON1505
Lifting Capacityton-meter42.0
Lifting Capacity / OutreachKg/m1,4000 / 2.5
Working Radiusm7.550 / 5.4
Max Working Heightm3900 / 9.1
Rated Oil Flow (1000 rpm)cc/rev2620 / 12.9
Working PressureKg/cm²1,930 / 16.7
Shape of Boom Hexagonal / 5 section / 2 cylinder
Boom LengthmMin. 5.73 Max. 20.9
Slewing Angledeg20.6
Wire RopeØ mm X mØ 14 X 100m (Hercules 19 X 7)
Hook Speedm/min15 (4th layer / 4 tall lines)
Truck Chassis, Recommendedton15.0 above
