ZTon 235 - Skylift
An Aerial Work Platform (AWP) is a mechanical device used to provide temporary access for people or equipment to inaccessible areas, usually at height. Aerial Work Platforms may provide additional features beyond transport and access, including being equipped with electrical qutlets or compressed air connectors for power tools
DESCRIPTION | UNIT | ZTON235 |
---|---|---|
Equipment Size (L X W X H) | mm | 5585 X 1930 X 2635 |
Equipment Weight | kg | 3200 |
Max. Working Height | m | 23.5 |
Max. Working Radius | m | 16 (100kg) |
Boom Type / Section | Octagon box / 5 boom | |
Boom Raising Angle | deg | -17 to 78 |
Boom Length | m | 4.08 to 17.03 |
Bucket Size (L X W X H) | mm | 1842 X 774 X 1150 (Outer size) |
Bucket Materials | FRP | |
Bucket Rotation Angle | deg | 360 (Limited) |
Max. Bucket Capacity | kg | 400 |
Outrigger Type (Front/Rear) | H type Fully Hydraulic / H type Fully Hydraulic | |
Outrigger Max Expanded Span (Front/Rear) | m | 5.69 / 5.69 |
Turntable Type | Hydraulic Motor Driven | |
Turntable Slewing | Worm & Spur Gear | |
Hydraulic Working Pressure | kg/cm² | 355 |
Pump Operation Type | 210 | |
Application Chassis (Pay Load) | ton | 2.5 ton and above |
Safety Devices | Pressure relief valve for hydraulic circuit, Boom raising and boom telescoping, Buzzer, Emergency light, leveling overcenter valve, Double Pilot check valves for vertical outrigger, Auto leveling system, Bucket tilting system, Emergency DC pump |
